คำอธิบาย
| Brand | LONGWELL |
| Model | P8H61-GL Rev3.0 |
| CPU Support | CPU Support Intel® 2nd/3rd Generation Core™ i3/i5/i7/Pentium®/Celeron® Processors |
| CPU Brand | Intel |
| Socket | 1155 |
| Chipset | Intel H61 |
| Memory Support | Memory Dual Channel DDR3 Memory Technology 2 x DDR3 DIMM Slots Support DDR3 1600/1333 MHz Non-ECC, Un-Buffered Max.capacity up to 16GB Memory |
| Maximum Memory Bus | 1600 |
| Graphics | N/A |
| Multi Graphic Support | None |
| Audio | Audio Realtek® ALC 661,662 Channel High Definition Audio CODEC |
| Expansion Slots | 1 x PCI Express 2.0 x16 (x16 mode) 1 x PCI Express 2.0 x1 |
| Maximum PCIe Version | PCIe 2.0 |
| Storage | 3 x SATA II 3.0Gb/s Connector 1 x M.2 NVME |
| M.2 Storage Type Support | NVMe |
| M.2 Slot | 1 |
| USB | 4 x USB 2.0 Port |
| Internal I/O Connectors | 1 x 24-pin ATX Power Connector 1 x 4-pin ATX 12V Power Connector 1 x CPU Fan Connector 1 x System Fan Connector 1 x USB 3.0 Connector 1 x USB 2.0 Connector 1 x Front Panel Audio Connector 1 x Speaker Connector |
| Back Panel Connectors | 1 x HDMI Port 1 x VGA (D-Sub) Port 4 x USB 2.0 Port 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) 3 x Audio Jacks: Line in / Speaker / Microphone |
| LAN | LAN 10/100/1000 Mb/s auto negotiation Half/Full duplex capability Realtek® RTL8111E |
| Wireless Data Network | None |
| Form Factor | Micro ATX |
| H/W Monitoring | N/A |
| BIOS | N/A |
| Special Features | N/A |
| Software Features | N/A |
| Operating System Support | Microsoft Window XP / Vista / 7 / 8 / 10 |
| Package Contents | 1 x SATA cable 1 x I/O Rear Panel 1 x User Manual 1 x CD Driver |
