คำอธิบาย
| Brand | D-LINK |
| Model | DGS-1008A |
| Network Interface | 8 x Ports 10/10/1000 Mbps |
| Standards and Protocols | IEEE 802.3 10BASE-T Ethernet (twisted-pair copper) IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper) IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted-pair copper) IEEE 802.3x Flow Control |
| Transmission Method | Store-and-forward |
| MAC Address Table | 8K entries per device |
| Packet Buffer Memory | 128 KBytes per device |
| LED Indicators | Link / Activity / Speed / Power |
| Features | Green Ethernet 16 Gbps switching fabric Auto MDI/MDIX crossover for all ports Secure store-and-forward switching scheme Full/half-duplex for Ethernet/Fast Ethernet speeds IEEE 802.3x Flow Control Supports 9,216 Byte Jumbo Frames Supports IEEE 802.1p QoS (4 Queues, Strict Mode) Supports Cable Diagnostics Function |
| MTBF | 522,270 hours |
| Network Media | Auto MDI/MDIX adjustment for all ports |
| Power Supply | 5 V/1 A Power Adapter |
| Power Consumption | Power On (Standby) : DC input : 0.59 watts, AC input : 1.5 watts Maximum: DC input: 3.48 watts, AC input: 5.4 watts |
| Environment | Temperature Operating: 0 to 40 °C (32 to 104 °F) Temperature Storage: -10 to 70 °C (14 to 158 °F) Humidity Operating: 10% to 90% non-condensing Humidity Storage: 5% to 90% non-condensing |
| Certifications | CE class B FCC class B ICES-003 Class B VCCI class B C-Tick Anatel CCC cUL CB LVD |
| Automatic Update | |
| Dimension | (W x D x H) : 13.10 x 8.20 x 2.20 cm |
| Net Weight | 0.01 KG |
| Package Dimension | (W x D x H) : 10.00 x 16.00 x 10.00 cm |
| Gross Weight | 0.27 KG |
| Volume | 1,600.00 cm3 |
