คำอธิบาย
| Brand | ZYXEL |
| Model | • FWA505 |
| Standards | • Wireless standard: IEEE 802.11b/g/n/a/ac/ax |
| Antennas | • Two TS9 connectors for external antennas • Four embedded omni-directional antennas • Antenna Spec (Peak Gain) – 700 MHz ~ 960 MHz: 2 dBi – 1.4 GHz ~ 2.7 GHz: 5 dBi – 3.3 GHz ~ 4.2 GHz: 5 dB
|
| Transmit/Receive | N/A |
| Frequency | • 2.4GHz , 5GHz |
| Range | N/A |
| Wireless Functions | • Multiple/Hidden SSIDs • NAT/NAPT firewall • DoS attack detection • WPA2 and WPA3 • SPI (Stateful Packet Inspection) • Application-level firewall • WLAN/LAN MAC filtering • IP filtering • URL filtering |
| Processor Specs | N/A |
| CPU CORE COUNT | N/A |
| Size of RAM | N/A |
| LEDS | • Power indication • Signal strength • Internet connection status • WiFi AP status • WPS status |
| Interface | • 2x 10/100/1000 Mbps Ethernet RJ-45 LAN • 1x Micro SIM Card Slot |
| USB Interface | • 1x USB 2.0 |
| Button | • One power on/off button • One WPS/WiFi on/off button • One reset button |
| Power Switch | N/A |
| Data Rate | 5G NR interface • 5G SA: DL 4.7 Gbps; UL 2.5 Gbps • 5G NSA: DL 3.7 Gbps; UL 1.5 Gbps • Supports DL modulation QPSK,16-QAM, 64-QAM, and 256-QAM • Supports UL modulation QPSK,16-QAM, 64-QAM, and 256-QAM 4G LTE interface • Max. DL 1.6 Gbps/UL 211 Mbps • Supports DL modulation QPSK,16-QAM, 64-QAM, and 256-QAM • Supports UL modulation QPSK,16-QAM, 64-QAM, and 256-QAM |
| Operation Mode | • Router |
| Management | • Supports local/remote device management and firmware upgrade via TR-069 and web GUI • PIN/PUK management • APN management • Operating frequency band selection • CLI/SSH (local and remote SSH access) • Supports UPnP IGD • Supports web server API to support APPs • Supports Zyxel Nebula app (iOS andAndroid) for easy installation and local management |
| Firewall | • DoS attack detection • Supports SPI • Application-level firewall (LAN to WAN such as FTP, HTTP, Telnet, Ping) • Filters LAN MAC address • Filters LAN IP address |
| VPN Support | • Virtual Private Network (VPN) pass-through |
| IPv6 support | • Supports IPv4/IPv6 dual stack (NDP IPv6) |
| Features | • 5G NR with up to 4.67 Gbps download rate • AX1800 WiFi 6 speeds up to 1.77 Gbps • 2.4/5GHz dual concurrent WiFi sharing with up to 64 devices • Nebula cloud app for easy set up & managemen • Full LAN Gigabit ports • Connection failover between both WAN interfaces |
| OS compatibility | N/A |
| System Requirements | N/A |
| Power Supply | N/A |
| Power Supply (PoE) | NONE |
| Power Consumption | • 24W (peak) |
| Environment | • Temperature : -10°C to 40°C (14°F to 104°F) • Humidity: 10% to 90% RH (non-condensing) |
| Certification | • CE • NCC • BSMI • NBTC Certification |
| Package Contents | • Power adapter • Ethernet cable 1.8 m 8P8C |
| Dimension | (W x D x H) : 10.30 x 10.30 x 22.20 cm |
| Net Weight | 1.14 KG |
