คำอธิบาย
| Brand | D-LINK |
| Model | DWR-M972V |
| Standards | 802.11a/b/g/n/ac(2*2) |
| Antennas | 2 x 2 MIMO antennas |
| Transmit/Receive | N/A |
| Frequency | LTE Bands FDD: B1/B3/B5/B7/8/B20/B28AB TDD: B38/B40/B41, WCDMA B3/B8, GSM/GPRS B3/B8 WCDMA : B3/B8 GSM/GPRS : B3/B8 CA : 1A+3A,5A+1A,7A+1A,8A+1A,20A+28A,1A+ 40A,1A+41A,3A+3A,3A+5A,3A 8A,3A+20A,3A+28A,3A+38A,3A+40A,3A+41A,5A+5A,5A+7A,5A+40A,7A+7A,7A 8A,7A+20A,7A+28A,8A+38A,8A+40A,8A+41A,28A+38A,28A+41A,40A+40A,41A+41A |
| Range | N/A |
| Wireless Functions | VoLTE call Wireless Encryption |
| Processor Specs | N/A |
| CPU CORE COUNT | N/A |
| CPU nominal frequency | N/A |
| Size of RAM | N/A |
| LEDS | 4G, WiFi, WPS, Battery, LAN |
| Interface | 1x 10/100/1000 Gigabit Ethernet WAN/LAN port 3x 10/100/1000 Gigabit Ethernet LAN ports 1x RJ11 1x Nano Sim Card Slot |
| USB Interface | 1x USB |
| Button | Power, Reset, WPS, WiFi |
| Power Switch | YES |
| Data Rate | LTE Cat 7 Downlink: Up to 300 Mbps LTE Cat 7 Uplink: Up to 100 Mbps DC-HSPA Downlink: Up to 42 Mbps1 DC-HSPA Uplink: Up to 5.72 Mbps WiFi Rates Up to 866Mbps@80MHz Up to 300Mbps@40MHz |
| Operation Mode | 3G/4G Router, Wireless Router |
| Management | N/A |
| Firewall | NONE |
| VPN Support | N/A |
| IPv6 support | N/A |
| Features | – Share your 3G/4G connection with multiple devices – Built-in LTE module for high speed mobile network access – Max physical data rates of up to 1200Mbps – Backwards compatible to IEEE 802.11b/g/n standards – Easy-to-use web GUI – 2 x 2000mAh battery included ( Last up to 2.5 Hours) |
| OS compatibility | N/A |
| System Requirements | N/A |
| Power Supply | Power 12V DC |
| Power Supply (PoE) | NONE |
| Power Consumption | N/A |
| Environment | Temperature Operating: : 0°C ~ +40°C Storage: -20°C ~ +70°C Humidity Operating: : 40°C/90-95% Storage: 10 ~ 95% |
| Certification | CE , RoHS Compliant |
| Package Contents | N/A |
| Dimension | (W x D x H) : 18.00 x 11.00 x 2.90 cm |
| Net Weight | 0.30 KG |
